Panel solar 120W24V silicio monocristalino módulo fotovoltaico no estándar monitoreo de carga exterior especificaciones de exportación
Código: WB-250528-2339
Hacer que importar sea más cómodo
Usted
Enviar lista de compra
CHILATSHOP Servicio
Ofrecemos cotización integrada con precios EXW (recogida en fábrica) o FOB (entrega en puerto de salida)
1
Selección y cotización
2
Confirmación y pago
3
Supervisión y control de calidad
4
Consolidación y transporte
5
Despacho aduanal y entrega
Atributos clave
| Tipo | Componentes monocristalinos |
| Voltaje de funcionamiento | 41.6 |
| Tipo de batería | Paneles solares, componentes |
| Modelo | XHGD-120W |
| Corriente de cortocircuito | 3.06A |
| Origen | Zhejiang |
Mostrar más
Descripcion
产品参数详情
| Module Type | XHGD-120W |
| Peak power(Pmax) | 120W |
| MPP voltage(Vmp) | 41.4V |
| MPP current(Imp) | 2.9A |
| Open circuit voltage(Voc) | 49.9V |
| Short circuit current(Isc) | 3.06A |
| Power Tolerance | ±3% |
| Operating Temperature | -40℃~+85℃ |
| Product certification | IEC/CE/ROHS |
| Dimensions | 910*680*30mm |
| No. of Cells | 72PCS(6*12) |
| Weight | 6.2kg |
| Front | 3.2mm tempered glass |
| Frame | Anodized aluminium alloy |
| Junction Box | IP65 |
| Output Cables | 2.5㎟*900mm |
| Connectors | MC4 compatible |
| Box Size | 127*8*69 |
| Packing Type | 2PCS/CTN |
| weight | 18KG |
182电池部分组件尺寸
工厂生产环境及设备流程
VI测试仪
层压机
小功率串焊机
多栅自动串焊机
叠层流水线
EL测试台
自动划片机
Venta por lotes: la cantidad añadida es el mínimo requerido
US$ 20.698
5-199 pcs
US$ 19.728
200-499 pcs
US$ 19.081
>=500 pcs
1. Modelo:
XHGD-120W
La cantidad indicada corresponde al pedido mínimo requerido por la fábrica; si necesitas ajustar la cantidad del producto, después de enviar el presupuesto, un gerente de compras hispanohablante se pondrá en contacto contigo para discutir los detalles del producto.
