ingeniería de construcción equipos de soldadura manual tubería disolución máquina de conexión eléctrica máquina de soldadura de tuberías termoplásticas
Código: WB-260106-4369
Hacer que importar sea más cómodo
Usted
Enviar lista de compra
CHILATSHOP Servicio
Ofrecemos cotización integrada con precios EXW (recogida en fábrica) o FOB (entrega en puerto de salida)
1
Selección y cotización
2
Confirmación y pago
3
Supervisión y control de calidad
4
Consolidación y transporte
5
Despacho aduanal y entrega
Atributos clave
| Marca | Victoria Checa |
| Forma de accionamiento | Eléctrico |
| Uso | Soldadura |
| Forma dinámica | CNC |
| Conjunto | Soldador de acoplamiento de fusión caliente |
Descripcion
本机适用于在沟渠或者工地上操作的PP PB PVDF材质的管件。由机架，铣刀，加热板和附件支架构成。由轻质高强度的材料制造而成。节省劳动力。机器主要部件由纯铝制造，比翻砂，钢模更轻便，坚固，光滑.
|
型号 |
63-160 |
63-200 |
90-250 |
|
焊接规格 |
63,75,90,110,125,140,160 |
63,75,90,110,125,140,160,180,200 |
63,75,90,110,125,140,160,180,200,225,250 |
|
对接偏差 |
≤0.3mm |
≤0.3mm |
≤0.3mm |
|
温度误差 |
±3°C |
±3°C |
±3°C |
|
耗电总功率 |
1.7kw/220V |
2.3kw/220V |
3.15kw/220V |
|
工作温度 |
220°C |
220°C |
220°C |
|
环境温度 |
零下5-40℃ |
零下5-40℃ |
零下5-40℃ |
|
达到焊接温度所需时间 |
<20min |
<20min |
<20min |
|
可焊接材料 |
PE PPR PB PVDF |
PE PPR PB PVDF |
PE PPR PB PVDF |
山东捷胜重工机械有限公司是济宁市高新区大型企业，是济宁市的生产制造企业。山东捷胜重工机械有限公司主要经营的各种矿建设备器材已销售到28个省市，出口20多个地区，并从德国、英国、法国进口了设备和器材，山东捷胜重工机械有限公司现有工程师16人，技术人员28人，技工150人，主要生产建筑机械、路面机械、矿山设备、园林机械等产品生产加工的公司。山东捷胜重工机械有限公司全体员工秉承信誉是生命、质量求生存、客户是衣食父母的原则，为国内外新老客户做出新的贡献而努力。 欢迎各界朋友莅临参观、指导和业务洽谈。
产品图片仅供参考，具体实物颜色，尺寸规格和款式以发货为准 ，工厂按订单顺序随机发货，无质量问题，不接受退换货。
US$ 483.333
>=1 pcs
1. Conjunto:
Soldador de acoplamiento de fusión caliente
1.Compra mínima de US$ 6,000 con productos combinados.
2.Mas cantidad, mejor precio.
