| Formas de trabajo | Semiautomático |
| Número de artículo | -- |
| Máximo ancho de mecanizado | 100 |
| Marca | Victoria Checa |
| Tipo de producto | Nuevo |
| Modelo | Rutina |
传统木榫（木塞、木梢）倒角机只能一段一段地对圆木条进行切割和倒角，很大程度上依赖于工人的熟练度，效率非常低，劳动强度大，成本较高，木榫等产品长度也难保证一致，倒角部位也容易起棱角，至使整体外形不美观。为了解决传统木榫倒角机械的缺点，本机型进行了全新的设计，效率高，平均班产切圆木条达八千至一万米，班产量30-40万粒，是传统木榫机械10倍以上且操作方便工人不需特别培训，产品长度一致，倒角质量美观，成品率高。
主机功率： 5.5kw(一个）
进给电机功率：0.75kw(一个）
主轴转速：3200r/min
送料速度：8000-13000米/8小时
处理直径：6-16mm
zui短处理长度：100mm
|
规格参数 |
main technical parameter |
MJ2912 |
|
截断直径 |
truncating diameter |
6/8/10/12mm |
|
截断长度 |
truncating length |
30-80mm（任意调节） |
|
截断效率 |
truncating efficiency |
30个/分 |
|
电机功率 |
truncating power |
0.55w |
|
额定电压 |
rated voltage |
380v |
|
外形尺寸 |
overall dimension |
600*480*950mm |
|
重量 |
weight |
约48kg |
山东捷胜重工机械有限公司是济宁市高新区大型企业，是济宁市的生产制造企业。山东捷胜重工机械有限公司主要经营的各种矿建设备器材已销售到28个省市，出口20多个地区，并从德国、英国、法国进口了设备和器材，山东捷胜重工机械有限公司现有工程师16人，技术人员28人，技工150人，主要生产建筑机械、路面机械、矿山设备、园林机械等产品生产加工的公司。山东捷胜重工机械有限公司全体员工秉承信誉是生命、质量求生存、客户是衣食父母的原则，为国内外新老客户做出新的贡献而努力。 欢迎各界朋友莅临参观、指导和业务洽谈。
产品图片仅供参考，具体实物颜色，尺寸规格和款式以发货为准 ，工厂按订单顺序随机发货，无质量问题，不接受退换货。
