| Número de artículo | js-sdi-596833 |
| Tipo | Máquina redonda |
| Marca | Victoria Checa |
| Uso | Máquina de enrollado de placa metálica CNC |
| Potencia del motor | 4 |
| Modelo | js-sdi-596833 |
主要用于各种规则圆形金属器皿制品、金属片压圆环；焊接式，扣骨式接合的直身圆筒制品的滚制。广泛用于摩托车/汽车行业、热水器行业和其他各领域。
1、主电机/油泵功率：4KW/3.75KW
2、油缸吨位：40T
3、主机架板厚：50MM
4、胶辊直径：400MM（单边胶厚：50MM)
5、上轴：140mm(45#调质处理）
6、轴承：双排调心圆柱轴承
8、长宽高/重量:2700*900*1300MM/1700KG
9、速度：6M/min
10、取料方式：液压侧开合门
11、卷板zui大宽度：1000mm
12、电力需求：三相380v
13、加工板材材质/厚度：Q235冷轧板/0.5-3mm,SUS304不锈钢/0.6-2mm
14、卷圆形式：两辊
15、结构形式：胶辊下置式
16、油箱容积：46号抗磨液压油100升
17、设备操作高度：1100mm
18、设备自动化程度：触摸屏，人工上料，自动卷制，手动卸料，带有自动模式和手动模式功能
山东捷胜重工机械有限公司是济宁市高新区大型企业，是济宁市的生产制造企业。山东捷胜重工机械有限公司主要经营的各种矿建设备器材已销售到28个省市，出口20多个地区，并从德国、英国、法国进口了设备和器材，山东捷胜重工机械有限公司现有工程师16人，技术人员28人，技工150人，主要生产建筑机械、路面机械、矿山设备、园林机械等产品生产加工的公司。山东捷胜重工机械有限公司全体员工秉承信誉是生命、质量求生存、客户是衣食父母的原则，为国内外新老客户做出新的贡献而努力。 欢迎各界朋友莅临参观、指导和业务洽谈。
产品图片仅供参考，具体实物颜色，尺寸规格和款式以发货为准 ，工厂按订单顺序随机发货，无质量问题，不接受退换货。
