| Ya sea para exportaciones transfronterizas | Sí. |
| Especificaciones | Bomba manual,Bomba eléctrica de 380V,Bomba eléctrica de 220V |
| Maquinaria aplicable | Consulta detallada |
| Número de artículo | js-scf-5628400 |
| Tipo | Máquina de prensado |
| Peso | 50 |
便携式压套机（电动、手动），本产品适用于各种履带工程机械设备轴套的压装，是工程机械维修企业常备的设备，此设备采用了双向液压装制，减少了油路，维修简便、操作灵巧，该机型分为电动和手动两种，用户可根据自己的实际情况自行选择。压套机是一种液压动力工具，为避免可能的重大人员伤害，使用前应仔细阅读所的说明、警告和注意事项。初次使用时油箱中须加满46#液压油后方可试机
便携式压套机是由空心缸、丝杠、梯形工装、旋转固定盘、液压泵站组合而成，利用液压能转变成机械能的原理，对履带式挖掘机钢套实施压装的机具。
以本厂产品大流量手动换向泵(适用于野外作业)，电动泵（220V，380V）作为动力源使液压缸快速向前运动，从而顺利将钢套压入。取代人力锤击的方法。保证钢套完好不受损伤。是履带挖掘机维修，装配中的工具。
油缸行程：100㎜
油缸推力：70T
油缸孔径：50mm
压套范围：60-120 mm(其它参数可订做)
手动油泵
工作压力（MPa）:高压:63 低压:1
zui大排量(ml/次):高压:2.3 低压:12.5
油箱容量(L):3L 介质：46#液压油
大排量手动换向油泵
手动换向泵zui大手摇力：50Kg
工作压力：高压0-63Mpa 低压 4Mpa
工作流量：高压流量 7ml/次 低压流量 50ml/次
油箱容量(L):13L 介质：46#液压油
电动泵
电机功率：1.5KW 220V或380V
工作压力：0-63Mpa 工作流量：1.2L/min
油箱容量(L):16L 介质：46#液压油
山东捷胜重工机械有限公司是济宁市高新区大型企业，是济宁市的生产制造企业。山东捷胜重工机械有限公司主要经营的各种矿建设备器材已销售到28个省市，出口20多个地区，并从德国、英国、法国进口了设备和器材，山东捷胜重工机械有限公司现有工程师16人，技术人员28人，技工150人，主要生产建筑机械、路面机械、矿山设备、园林机械等产品生产加工的公司。山东捷胜重工机械有限公司全体员工秉承信誉是生命、质量求生存、客户是衣食父母的原则，为国内外新老客户做出新的贡献而努力。 欢迎各界朋友莅临参观、指导和业务洽谈。
产品图片仅供参考，具体实物颜色，尺寸规格和款式以发货为准 ，工厂按订单顺序随机发货，无质量问题，不接受退换货。
