| Propósito | Tubería |
| Especificaciones | Dobladora de tubería hidráulica automática |
| Tipo | Doblador de tubería |
| Si la exportación transfronteriza está disponible exclusivamente | No |
| Peso | 0,95 |
| Número de pedido | Js-wgj-2301 |
本机适用于造船业、锅炉、大型运输车辆、石化工业、休闲家具业、电厂及工程配管等。
运输业：机车/汽车/自行车-排气管，剎车/供油管路，方向器，空调管路，座椅，平衡器，保险杆，窗框/车把，车架等。
家俱业：室内外桌椅，办公桌椅，架子，床类等家具。
休闲业：健身器材，童车，婴儿车，游乐设施。
冷暖业：热水器，电热器，冰箱，冷气等。
重工业：锅炉，电厂，化工厂，柴油引擎，造船等配管。
其它业：家用品，复健医/疗器材，卫浴设备，装饰业，建筑业，农业，航/空业。
|
|
单位 |
38NC型 |
|
zui大钢管 |
mm |
38×1.6 |
|
zui大不锈钢管 |
mm |
32.6×1.5 |
|
zui大方管 |
mm |
32×1.5 |
|
弯曲zui大半径范围 |
mm |
45-350 |
|
弯曲角度范围 |
degree |
0-190 |
|
每管件设定弯曲数量 |
个 |
无限制 |
|
资料输入方式 |
|
手工输入弯管角度和其它参数 |
|
弯管主油缸直径 |
mm |
80 |
|
弯曲速度 |
Deg/sec |
30（速度可调） |
|
弯曲精度 |
degree |
±0.15 |
|
油泵电机功率 |
KW |
4 |
|
液压系统压力 |
Mpa |
12 |
|
机器毛重 |
T |
0.95 |
|
机器外型尺寸 |
mm |
2500×900×1400 |
山东捷胜重工机械有限公司是济宁市高新区大型企业，是济宁市的生产制造企业。山东捷胜重工机械有限公司主要经营的各种矿建设备器材已销售到28个省市，出口20多个和地区，并从德国、英国、法国等进口了设备和器材，山东捷胜重工机械有限公司现有工程师16人，技术人员28人，技工150人，主要生产建筑机械、路面机械、矿山设备、园林机械等产品生产加工的公司。山东捷胜重工机械有限公司全体员工秉承信誉是生命、质量求生存、客户是衣食父母的原则，为国内外新老客户做出新的贡献而努力。 欢迎各界朋友莅临参观、指导和业务洽谈。
产品图片仅供参考，具体实物颜色，尺寸规格和款式以发货为准 ，工厂按订单顺序随机发货，无质量问题，不接受退换货。
