P2.5P3P4P5P10 al aire libre a prueba de agua pantalla de visualización LED en color LED Dispaly publicidad pantalla grande
Código: WB-260202-4254
Hacer que importar sea más cómodo
Usted
Enviar lista de compra
CHILATSHOP Servicio
Ofrecemos cotización integrada con precios EXW (recogida en fábrica) o FOB (entrega en puerto de salida)
1
Selección y cotización
2
Confirmación y pago
3
Supervisión y control de calidad
4
Consolidación y transporte
5
Despacho aduanal y entrega
Atributos clave
| Origen | Shenzhen |
| Número de artículo | Consulta al servicio al cliente |
| Marca | Qzg - Qin zhiguang |
| Sistema de control | Nova / escala de grises / kalet / lingxingyu / mosil / kaishida / Avic / yangbang / |
| Modelo | P10,P8,P6,P5,P4,P3,P2.5,P2 |
| Mostrar color | Todo color |
Mostrar más
Descripcion
模组参数
Unit Module
项目 Item 参数 Parameter
产品型号 Model Number QZG-P2.5-64S
模组尺寸 Module size 320mm*160mm
物理点间距 Pixel pitch 5mm
物理密度 Pixels Density 40000点/m2
发光点颜色 Pixel configuration 1R1G1B
LED封装 Package mode SMD 3IN1 -1921
模组分别率 Pixel resolution 256dots(W)*128dots(H)
模组最大功耗 Max Power 18W
模组厚度 Module thickness 15mm
模组重量 Weight 0.55KG
驱动方式 Drive type 恒流驱动Constant drive
扫描方式 Scan mode 1/8扫描 1/16scan
接口方式 Port type HUB75E
白平衡亮度 Brightness of white balance ≥5500cd/㎡
户外LED全彩显示屏的详细参数
以下是关于P2.5P3P4P5P8P10户外LED显示屏的一些详细参数，这些参数可以帮助您更好地了解该产品的性能和技术规格。
像素间距和物理密度
- 像素间距：P2.5P3P4P5P8P10mm
- 物理密度：64*32点
显示规格
- 屏体分辨率：不同供应商提供的分辨率有所不同，例如64×64点或者128×256点
- 显示基色：全彩
- 像素组成：1R1G1B（即每个像素由一个红色、一个绿色和一个蓝色发光二极管组成）
- 可视角度：水平160度，垂直160度
- 可视距离：4～160m或者3.91-100m
亮度和色温
- 白平衡亮度：≥5500cd/m²或者6000cd/m²
- 色温：6500k-9500k可调
电气规格
- 工作电压：220V±10%和110V±10%可选
- 平均功耗：300～440W/m²或者280W/m²
- 最大功率：≤800W/㎡
控制系统
- 控制主机：台机商务电脑，建议使用双核CPU，具有PCI插槽1
- 控制方式：同步控制
- 刷新频率：≥2000帧/m
其他参数
- 使用寿命：100000小时
- 产品重量：6Kg/m²
- 存储温度：-40-85℃
- 工作温度：-20-60℃
安装方式
户外LED全彩显示屏一般采用多种安装方式，包括镶嵌式、吊装式、普通挂装、旋转支架挂装、落地式、摆臂式等
Venta por lotes: la cantidad añadida es el mínimo requerido
US$ 20.213
1-99 pcs
US$ 19.404
100-999 pcs
US$ 17.787
>=1000 pcs
1. Modelo:
P10
P8
P6
P5
P4
P3
P2.5
P2
La cantidad indicada corresponde al pedido mínimo requerido por la fábrica; si necesitas ajustar la cantidad del producto, después de enviar el presupuesto, un gerente de compras hispanohablante se pondrá en contacto contigo para discutir los detalles del producto.
