Panel solar fotovoltaico 300W África venta caliente panel solar de alta eficiencia fuente fábrica de Yiwu generación de energía fuera de la red 24V
Código: WB-250528-2137
Hacer que importar sea más cómodo
Usted
Enviar lista de compra
CHILATSHOP Servicio
Ofrecemos cotización integrada con precios EXW (recogida en fábrica) o FOB (entrega en puerto de salida)
1
Selección y cotización
2
Confirmación y pago
3
Supervisión y control de calidad
4
Consolidación y transporte
5
Despacho aduanal y entrega
Atributos clave
| Tipo | Componentes monocristalinos |
| Voltaje de funcionamiento | 34.5 |
| Tipo de batería | Paneles solares, componentes |
| Modelo | XHGD-300W |
| Marca | Xinhao Sunshine/xinhaosolar |
| Corriente de cortocircuito | 9.18A |
Mostrar más
Descripcion
产品参数详情
| Module Type | XHGD-300W |
| Peak power(Pmax) | 300W |
| MPP voltage(Vmp) | 34.5V |
| MPP current(Imp) | 8.7A |
| Open circuit voltage(Voc) | 41.4V |
| Short circuit current(Isc) | 9.18A |
| Module efficiency | 20.7% |
| Power Tolerance | ±3% |
| Operating Temperature | -40℃~+85℃ |
| Product certification | IEC/CE/ROHS |
| Dimensions | 1640*992*35mm |
| No. of Cells | 60PCS(5*12) |
| Weight | 17kg |
| Front | 3.2mm tempered glass |
| Frame | Anodized aluminium alloy |
| Junction Box | IP65 |
| Output Cables | 4㎟*900mm |
| Connectors | MC4 compatible |
| Box Size | 167*8.5*90cm |
| Packing Type | 2PCS/CTN |
| weight | 27kg/CTN |
182电池部分组件尺寸
Venta por lotes: la cantidad añadida es el mínimo requerido
US$ 37.191
300-999 pcs
US$ 35.574
>=1000 pcs
1. Modelo:
XHGD-300W
La cantidad indicada corresponde al pedido mínimo requerido por la fábrica; si necesitas ajustar la cantidad del producto, después de enviar el presupuesto, un gerente de compras hispanohablante se pondrá en contacto contigo para discutir los detalles del producto.
